DZL Series Coal-Fired/Biomass Hot Water Boiler
Fill out my online form.
Product Description
Rated thermal power: 0.7–7 MW; Rated working pressure: 0.7/1.0/1.25/1.6 MPa; The water temperature: 95/115/130℃; Return water temperature: 70℃; Designed thermal efficiency: 80–82.3%; Fuel consumption: 129–1707.8 kg/h; Fuel: Coal, biomass, etc. The boiler adopts the latest research results, such as: arched tube plate, screw-thread smoke tube, hot-water boiler backwater ejection technology. Boiler water circulation progresses on natural circulation and ejection.
Technical Parameters
| DZL Coal-fired/biomass Hot Water Boiler | ||||||||
| Type | DZL0.7 | DZL1.4 | DZL2.8 | DZL4.2 | DZL5.6 | DZL7 | ||
| Project | Unit | |||||||
| Rated thermal power | MW | 0.7（600000 kcal/h) | 1.4(1.2 million kcal/h) | 2.8(2.4 million kcal/h) | 4.2(3.6 million kcal/h) | 5.6(4.8 million kcal/h) | 7(6million kcal/h) | |
| The rated steam pressure | Mpa | 0.7、1.0、1.25、1.6 | ||||||
| The water temperature/return water temperature | ℃ | 95/70、115/70、130/70 | ||||||
| Avaible fuel | （AⅡ) | |||||||
| Design the thermal efficiency | ％ | 80.2 | 80.8 | 80 | 82.3 | 80.3 | 80.8 | |
| The fuel consumption | Kg/h | 129 | 351.3 | 693 | 1041.9 | 1089 | 1707.8 | |
| The transport dimension | 5200*2100*3000 | 5525*2440*3400 | 6081*2450*3500 | 8000*2700*3550 | 8000*2900*3550 | 8980*3200*3600 | ||
| Boiler installation structure | The fast The assembly | |||||||
