LDR0.2 Integrated Electric Steam Boiler
Fill out my online form.
Product Description
Rated steam capacity: 200 kg/h; Rated working pressure: 0.7/1.0 MPa; Saturated steam temperature: 170/193℃; Input power: 144 kW; Rated voltage: 3N AC 50Hz 380V; Fuel: Electric heating; Industry: Foods, Garment, Textile, Paper, Brewery, Rice mill, Dairy Products, Laundry, Poultry Feed, Package, Plywood, Building Material, Chemical, etc. Vertical-design electric steam boiler, nearly 100% thermal efficiency – quiet, clean, more in line with environmental requirements, no atmospheric emissions, NOx (nitrogen oxides).
1.All electrical components with CE and UL marks – ensure safety and long service life.
2.Quick start and stop, large operation load-adjusting range, easy handling.
3.Each heating element uses a concentrated beam flange connection, independently arranged; simple structure, high mechanical strength, safe, reliable, convenient replacement, and long service life.
4.Flexible working methods, can be set to either manual or automatic mode.
5.Unique power-switching function, can be regulated based on actual steam demand, making usage time/frequency consistent and improving equipment service life.
6.When one heating-element group has a problem, it can immediately stop operating the damaged heating group and cut off the power supply.
7.Vertical structure, compact and beautiful, elegant style, classic color, space-saving and easy installation.
2.Quick start and stop, large operation load-adjusting range, easy handling.
3.Each heating element uses a concentrated beam flange connection, independently arranged; simple structure, high mechanical strength, safe, reliable, convenient replacement, and long service life.
4.Flexible working methods, can be set to either manual or automatic mode.
5.Unique power-switching function, can be regulated based on actual steam demand, making usage time/frequency consistent and improving equipment service life.
6.When one heating-element group has a problem, it can immediately stop operating the damaged heating group and cut off the power supply.
7.Vertical structure, compact and beautiful, elegant style, classic color, space-saving and easy installation.
Technical Parameters
| LDR Vertical Electric Heating Steam Boiler | ||||||
| Type | LDR0.15 | LDR0.2 | LDR0.3 | LDR0.5 | ||
| Project | Unit | |||||
| Rated evaporation | t/h | 0.15 | 0.2 | 0.3 | 0.5 | |
| Rated working pressure | MPa | 0.7/1.0 | 0.7/1.0 | 0.7/1.0 | 0.8/1.0 | |
| Staturated steam temperature | ℃ | 170/193 | 170/193 | 170/193 | 170/193 | |
| Input Power | KW | 108 | 144 | 216 | 360 | |
| Input current | A | 162 | 216 | 324 | 540 | |
| Rated pressure | V | 3N AC 50Hz 380V | ||||
| Power×Group | KW×P | 18×6 | 18×8/24×6 | 27×8 | 36×10 | |
| a Main steam valve diameter | DN | 25 | 25 | 32 | 50 | |
| b Safety valve diameter | DN | 25 | 25 | 25 | 40 | |
| c Inlet diamater | DN | 15 | 15 | 25 | 25 | |
| d Blowoff Valve diameter | DN | 25 | 25 | 40 | 40 | |
| Overall size | L | mm | 1100 | 1150 | 1300 | 1450 |
| W | mm | 950 | 950 | 1100 | 1350 | |
| H | mm | 1950 | 2000 | 2100 | 2300 | |
| Weight | kg | 350 | 450 | 680 | 980 | |
| We can provide customized products for specific power supply in the world. | ||||||
